Automatic bottle sides labeling machine

FOB Price:1 - 10000 USD/Set

Min.Order Quantity: 1 Set
Supply Ability: 1 Set(s) per Month
Shipping: 30DAYS
Payment Terms: T/T
Update Time: June 8, 2017, 6:42 a.m.
In Stock
Product Details
Export Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin: Zhejiang in China
Quick Details
  • Weight:  600kg
  • Dimension(L*W*H):  2200（L） 1350（W） 1500（H）mm
  • Voltage:  220V 380V
  • Automatic Grade:  automatic
  • Brand Name:  MANCAN

Specifications



                      Automatic bottle sides labeling machine






The Technical Parameter

Model

SLM-A

Driving Mode

Servo motor

Yield（pcs/min）

60-160

Operating direction

Left or Right

Conveyor Speed（m/min）

≤40

Labeling Accuracy

±1.0 mm

The inner diameter of label roll

76 mm

The outer diameter of label roll

350 mm(max)

The suitable size of label

Width 15-150 mm  length 15-300 mm

The suitable size of label objects

Can customized

Power（w）

600W

Printer use air

5kg/cm ²

Voltage (In China)

AC220V 50/60HZ Single phase

(Can customized as buyer need)

Weight（kg）

260

Size of machine

2200（L） 1350（W） 1500（H）mm
