FOUR COLORS FLEXO PRINTING MACHINE
Performance and Characteristics:
Introduce sensitization resin as flexible printing plate, suitable for printing such packing materials as polyethylene, polypropylene bag, cellophane and roll paper,etc. It is a kind of ideal printing equipment for producing paper packing bag for food,supermarket handbag, vest bag and clothes bag, etc.
1.simple operating, soft starting, accurate color register.
2.meter counter can set printing quantity, automatic shutdown, automatic stop-off material.
3.pneumatic landing plate cylinder, automatic mixing ink after lifting.
4.the knurled cylinder with ink, ink evenly.
5.Reliable drying system coordinated with high-speed operation, automatic shutdown circuit. 6,360 degrees continuous and adjustable longitudinal photo checking device.
7. frequency control, adapt to different printing speeds.
8. the roller seats and rewind shelves are loaded moving and stop buttons, easy to operate when the machine is installed.
Technical Parameter:
Model No. | YT-4600 | YT-4800 | YT-41000 |
Max.Web Width | 600mm | 800mm | 1000mm |
Max.Effective Printing Width | 560mm | 760mm | 960mm |
Range of Repeat Printing Length | 191-914mm | 191-914mm | 191-914mm |
Max.Diameter of Material Roll | φ450mm | φ450mm | φ450mm |
Printing Speed | 5～50m/min | 5～50m/min | 5～50m/min |
Plate Thickness(Both side adhesive tape included) | 2.38mm | 2.38mm | 2.38mm |
Total Power | 10.87kw | 12.5kw | 14.37kw |
Weight of Machine | 3000kg | 3500kg | 4000kg |
Machine Dimension(mm) | 4200*1600*2400 | 4200*1800*2400 | 4200*2000*2400 |
|
|
|
|
